2015年5月22日星期五

3-D Printing Will Change the World


Amazing Items Made with 3D Printers

2015年5月21日星期四

XINJE HMI THA62-UT 10.1 Inch 800*480

Product description
10.1 inch touch screen, streamline design
65536 true colors display, support BMP, JPEG format pictures
Rich 3D picture library can make the screen more vividly
Flexible component selection space, self-defined animation track design
Simple switch setting for changing the modes, precise touch area adjust function
Self-defined data collection and save function
Support various data process modes, such as time trend map, XY trend map…
2 USB ports can realize data duplication and transferring
Two com ports can communication independently and realize multi-THs communicate with one PLC.

Type notes:
MT: standard
UT: with USB-A port
Specifications:
Item THA62
Electrical Input voltage DC20-DC28V
Consumption current 630mA
Momentary power off allowance Less than 10ms
Withstand voltage AC1000V-10mA 1 minute ( signal and time )
Insulated impedance DC500V- about 10MΩ ( signal and time )
Interface COM1 Support RS-232/RS-485
COM2 Support RS-232/RS422/RS485
USB1 USB-A ( accord with USB2.0 )
USB2 USB-B ( accord with USB2.0 )




Environment Operation temperature 0-50℃
Reserve temperature -20-60℃
Environment temperature 20-85% ( no condensation )
Withstand oscillation 10-25Hz ( X, Y, Z each direction 30 minutes 2G )
Anti-jamming Voltage noise: 1000Vp-p, pulse 1us, 1 minute
Surrounding air No corrosive gas
Protection construction IP65
Screen specification Type 65536 true colors
Screen size 10.1 inch
Use life More than 50000 hours,24 hours running when surrounding temperature is 25 ℃
Resolution 800*480
Contrast Non-adjustable
Character Chinese, English, Korean, Japanese…
Character size Any size and font
Touch panel 4-wire resistance mode
Memory Screen 128MB
Construction Cooling method Natural air cooling
Exterior dimension 272.2*191.7*51.2mm
Mounting dimension 260.2*179.7mm
More Infomation THA62-UT: https://www.fasttobuy.com/hmi-101-800480-128mb-usb-port-tha62ut-with-programming-cable-new_p25802.html

2015年5月14日星期四

Typical circuit diagram of Star Delta starter

S0 = ‘OFF’ Push button
S1 = ‘ON’ Push button
K1 = Line contactor
K2 = Star contactor
K3 = Delta contactor
K4 = Star delta timer (7PU60 20)
F2 = Overload relay
F1 = Backup fuse
F3 = Control circuit fuse
This is a starting method that reduces the starting current and starting torque. The device normally consists of three contactors, an overload relay and a timer for setting the time in the star-position (starting position). The motor must be delta connected during a normal run, in order to be able to use this starting method. The received starting current is about 30% of the starting current during direct on line start and the starting torque is reduced to about 25 % of the torque available at a D.O.L start. This starting method only works when the application is light loaded during the start. If the motor is too heavily loaded, there will not be enough torque to accelerate the motor up to speed before switching over to the delta position. When starting up pumps and fans for example, the load torque is low at the beginning of the start and increases with the square of the speed. When reaching approx. 80-85% of the motor rated speed the load torque is equal to the motor torque and the acceleration ceases. To reach the rated speed, a switch over to delta position is necessary, and this will very often result in high transmission and current peaks. In some cases the current peak can reach a value that is even bigger than for a D.O.L start. Applications with a load torque higher than 50 % of the motor rated torque will not be able to start using the start-delta starter.

Wiring of Star Delta Starter with Timer Control Panel


PLC Program for Star Delta Starter

Note:Only for Simulation.

2015年5月8日星期五

   3D COMPUTER AIDED DESIGN AND MANUFACTURE

3D Design software such as Pro/DESKTOP® allows the designer to produce three dimensional representations of his/her ideas. When completed the design can be viewed on the screen and it can even be revolved and examined at any angle. 3D software such as Pro/DESKTOP® is much more complex than 2D software such as TechSoft 2D design. It requires specialist training before it can be used competently.
1. The designer draws up the design using software such as Pro/DESKTOP®. The design can be examined in detailed and if modifications/alterations are needed they can be made on the screen.Software of this type allows the designer to model his/her idea on the screen rather than make/manufacture an expensive model. Good 3D software allows the designer to design almost any item.
2. The design is processed. When the design has been completed using Pro/DESKTOP® it must be exported as a stereo lithography file. This type of file can be imported into processing software such as Boxford’s 3D-GeoCAM which converts the drawing into a long list of coordinates. Each set of coordinates is called a GM code.
3. Most CAD/CAM software allows the designer to test the manufacture of his/her design on a computer rather than actually making it. This saves time and materials. Testing designs is carried out using ‘simulation’ software. When the design is run through simulation software the computer displays the manufacturing on the screen. It also checks whether or not the design can be manufactured successfully. Many designs have to be altered before they can be made by a CNC machine.
4. An advanced CNC machine such as the A3 HSRi² (Boxford Machine Tools, Halifax, England)
 can be used to manufacture the three dimensional product. This CNC is both fast and accurate
 making suitable for school and industrial use.











2015年5月6日星期三

New Kinco HMI MT4414TE-CAN USB Host Ethernet with Software

MT4000 series HMI use 32-bit RISC CPU and streamlined LINUX kernel, you can display a variety of true-color graphics format, and its superior processing speed and software to meet the needs of most users. Support and the vast majority of the PLC to communicate directly, and can easily exchange data between their connected devices. MT4000 series has a direct line simulation, indirect line simulation, high-capacity user configuration program memory space, compatible with the standard C language macro functions fit the customer needs quickly and effectively complete the field data collection, computing, control.



Features:
(1)65536 color TFT display, supports BMP, JPG, GIF, and other format images import;
(2)High-performance 32-bit 400MHz RISC CPU, fast processing capability to protect the higher work efficiency;
(3)4.3 "to 12.1" wide range of display size;
(4)MT4000E configuration 10M/100M adaptive Ethernet interface;
(5)The integration 1USB the Slave and a DB15/DB25 printer interface;
(6)A powerful the EV5000 configuration software function to support the C language macro script;
Specifications:
MT4414TE-CAN
Display: 7” 16:9 TFT
Color: 65536 Colors
Memory: 128M FLASH + 64M SDRAM

Model
MT4414T
MT4414TE
MT4414TE-CAN
Performance specification
Display
7" 16:9 TFT
Resolution
800*480
Color
65536
Backlight
LED
Brightness
300cd/m2
Backlight life
50000 hours
Touch Panel
4-wire precision resistance network
Processor
32-bit 400MHz RISC
32-bit 800MHz RISC
Memory
128M FLASH + 64M SDRAM
U Disk
None
1 USB host
SD Card
None
Recipe memory & RTC
512KB + RTC
Printer port
Serial port
Serial port/USB port
Ethernet
None
Support
Program download
USB SLAVE/Serial port
USB SLAVE/Serial port/Ethernet port
COM port
COM0:RS232/RS485-2/RS485-4,COM2:RS232
Expansion Port
None
CANopen
Software
EV5000 V1.6
Electrical specification
Rated power
4W
Rated voltage
DC24V
Input range
12~28VDC
Power down allowed
<3ms
Insulation resistance
Greater than 50MΩ@ 500V DC
Dielectric strength test
500 VAC 1 minute
Structure specification
Shell color
Black
Shell material
ABS
Dimensions(mm)
204×150×37mm
Cutout size(mm)
192×138mm
Weight
0.75 Kg
Environment specification
Operating temperature
0~45 °C
Operating humidity
10~90% non-condensing
Storage temperature
 -10~60 °C
Storage humidity
10~90% non-condensing
Shockproof test
10~25Hz (X, Y, Z direction, 2G, 30 minutes)
Cooling method
Natural air cooling
Certification
Degree of protection
IP65 (front panel)
CE certification
Comply with EN61000-6-2:2005 and EN61000-6-4:2007standards
FCC compatibility
Complies with FCC Class A

All Kinco series products use HMI configuration editing software (official version): _Kinco HMI software_V2.2_Build131108 (Automatically install driver)
MT4000 series HMI adopts 32 bits RISC CPU and LINUX inner core
MT5000 series HMI adopts powerful intel PXA270 520MHz processor and high-efficiency LINUX system
Human Interface: CE Certification(including MT6000,MT5000,MT4000,MT500 and Text series)
Language: English

More info View here:
http://www.fasttobuy.com/7-hmi-800480-mt4414tecan-usb-host-ethernet-with-free-programming-cablesoftware-new_p26929.html
